PEEK powder is made by grinding the coarse powder obtained after PEEK polymerization. Powders of different sizes can be produced through different grinding processes. PEEK5600P fine powder is a powder with a medium melt flow rate, suitable for processing methods such as compression molding and spraying.
PEEK Properties
| Test items | Test standards or instruments | unit | PEEK5600P |
|---|---|---|---|
| Mechanical properties | |||
| Tensile strength (23℃) | ISO 527-2/1B/50 | MPa | 95 |
| Tensile modulus (23℃) | ISO 527-2/1B/51 | GPa | 4.0 |
| Elongation at break (23℃) | ISO 527-2/1B/50 | % | 25 |
| Bending strength (23℃) | ISO 178 | MPa | 169 |
| Flexural modulus (23°C) | ISO 178 | GPa | 4.2 |
| Compression strength (23℃) | ISO 604 | MPa | 125 |
| Simple supported beam impact strength (unnotched) | ISO 179/U | KJ/m 2 | No break |
| Izod impact strength (notched) | ISO 180/A | KJ/m 2 | 6 |
| Thermal performance | |||
| Melting point | DSC | ℃ | 343 |
| Heat deformation temperature | ISO 75-1/-2 | ℃ | 155 |
| Continuous use temperature | UL 746B | ℃ | 260 |
| Coefficient of thermal expansion | ASTM D696 | ppm K-1 | 46 |
| Flammability rating | UL 94 | / | V-0 |
| Thermal conductivity | ISO 22007 | W/（m ·K） | 0.28 |
| Electrical properties | |||
| Dielectric strength | IEC 60243-1 | KV/mm | 18 |
| Dielectric constant | IEC 60250 | – | 3.2 |
| Surface resistance | IEC 61340 | Oh | 1016 |
| Lossy dielectric | IEC 60251 | – | 0.004 |
| Other performance | |||
| color | – | True Color | |
| Actual density | ISO 1183 | g/cm 3 | 1.30 |
| Water absorption rate (25℃.24Hrs) | ISO 62 | % | 0.05 |
| Molding shrinkage (25-24℃) | 3mm thickness, 170°C flow direction |
% | 1.0 |
| Perpendicular to the flow direction | % | 1.3 | |
| Poisson’s ratio | ISO 527-2 | 0.4 | |
| Rockwell hardness | GB/T 3398.2 | HRR | 118 |
| Friction coefficient | ASTM D3702 | m | 0.30-0.35 |
| Melt index | ISO 1133 | g/10min | 10 |
